Use the Queue feature for example to combine and cascade multiple GIF animation, still images, and scrolling text events.Ī Pixelcade Listener called pixelweb.exe (Windows) or pixelweb.jar (for Raspberry Pi and Mac) runs in the background and listens for REST URL calls. Take things farther with the open source and REST based Pixelcade API and create additional use cases.

You can however de-solder a resistor jumper and change the address and then will be able to display something different on the second OLED display.

This means the same output will be displayed on each display. The Mini OLED displays are I2C devices and have the same address. In this installation, we're daisy chaining two Max7219 Dot Matrix Displays and two Max7219 7Segment Displays. If you are using jumper wires, I'd recommend to use Kapton or similar tape to secure the jumpers to the Arduino headers so they don't fall out. You can use jumper wires to connect or as I did, make a custom cable using Du Pont connectors. The architecture diagram shows how the Pixelcade software communicates with the LED marquee via the PIXEL board and sub-displays connecting via an Arduino.Īrduino Sketch (note in the sketch the additional libraries you'll need to install too) Modding the Arcade1Up control which includes the sub-displays and spinner. Some of the above product links are affiliate links which means I’ll receive a small commission at no extra cost to you. Misc Hardware (Various Sized M2 and M3 screws)ġ 1/8" Drill Bit to Drill Arcade Button HolesĭISCLAIMER: I am the creator and sell the Pixelcade LED marquee. LogiTech K400 Wireless Keyboard and Mouse LCD Controller Board (Adds HDMI to Arcade1Up Monitor)ħ Port Powered USB Hub (a non-powered USB hub will not work) LED Buttons, Joysticks, 2 USB Encoders, & Cables Pixelcade Sub-Display Kit (Includes Seeeduino, 1 Mini-OLED, 1 Max7219 Dot Matrix, and 1 Max7219 7Segment all with soldered vertical headers)ĭell OptiPlex 9020 Small Form Factor Computer (Refurbished) ****April 2020 Update // Software support added for virtual pinball, more at ****Īn Arcade1Up arcade cabinet modded with an LED marquee and additional smaller, sub-displays that show game information like game title, year, manufacturer, genre, and rating.Īrcade1Up Mortal Kombat Cabinet Amazon or Arcade1Up Mortal Kombat at Walmart
